Tenda TX9 AX3000 Dual Band Gigabit Wi-Fi 6 Router

TENDA AX3000 Dual Band Gigabit Wi-Fi 6 Router

TX9 is an AX3000 Wi-Fi 6 router with dual-band concurrency rate of up to 2976Mbps (2. 4GHz: 574Mbps, 5GHz:2402Mbps). It's equipped with dual-core 1.6GHz CPU, providing powerful processing capacity and more stable operation. TX9's 2.4GHz & 5GHz adopt external FEM design simultaneously to improve spectrum utilization and communication efficiency. By OFDMA+MUMIMO technology, the network latency is reduced, more devices can be connected to the Internet at the same time and the transmission efficiency is significantly improved. TX9 supports IPv6, WPA3, and comprehensively improves Wi-Fi experience.

Ultra-speed with Powerful Wi-Fi 6
Both dual-band of TX9 supports the new generation of Wi-Fi 6 technology, dual-band concurrent rate up to 2976Mbps (2.4GHz: 574Mbps, 5GHz: 2402Mbps), which is 66% faster than the peak speed of the AX1800. Just enjoy an incredible Internet experience with Wi-Fi 6.

Stable Connection with Dual-core Processor
The data processing capability is comprehensively improved with a dual-core processor with a main frequency of up to 1.6GHz and NPU. The core can boost capacity and reduces interference for smoother 4k video streaming and AR/VR gaming.

Dedicated Strong Signal for Reliable Network
With 4 independent FEMs and 4*external dual-band 6dBi omnidirectional antennas, TX9 fully improves signal power and receiving sensitivity, and achieves Wi-Fi 6 signal coverage for small and medium-sized houses.

Less Network Congestion with 160MHz
The 5G frequency band supports 160MHz ultra-high bandwidth, which can double the speed compared to 80MHz, making it easy for multiple people to play online without worrying about network congestion.

Four Gigabit Ethernet Ports
TX9 provides 4 gigabit ethernet ports, which can make full use of every megabit of the operator's bandwidth, video entertainment, e-sports games can experience a silky fast network.

Blazing Fast and Secure Wi-Fi
With IPv6 Technology, TX9 can effectively reduce data transfer links and improve transmission efficiency. At the same time, its security performance can effectively protect data and make Internet access more enjoyable and secure.

Refresh Your Internet Experience
TX9 supports a wide variety of functions such as signal adjustment, network detection, guest network control, parental control, blacklist/whitelist, timer switch, etc., aims to provide the pleasant experience of surfing the Internet at home.

General

Brand:	Tenda
Series:	TX9
Release date:	May 2021
Package Dimensions:	335 x 280 x 60mm (L x W x T)
Categories:	Computers > Accessories Promotions Computers > Networking > Modems & Routers > Network Routers
LSN:	XBR-C1G-M5L-2
Barcode:	6932849426359
Colour:	White
Model Number:	TX9
Type:	Router

Configuration

Universal Plug And Play (UPNP):

Yes

Security

Security:	WPA-PSK,WPA2-PSK, WPA/WPA2-PSK • WPA3-SAE/WPA2-PSK • WPS Fast connection
Security Algorithms:	WPA-PSK • WPA2-PSK

Other Features

Firewall Security :

ICMP Flood Attack Defense • TCP Flood Attack Defense • UDP Flood Attack Defense • Ignore Ping Packet From WAN Port

Power

Power Source:

AC

Specification

Data Rates:	2.4GHz & 5GHz
Frequency Band:	5GHz: 2402Mbps • 2.4GHz: 574Mbps
Network Protocols:	PPPOE, Dynamic IP, Static IP
Protocols / Topology:	IPv4 & IPv6
Standards:	802.11b/g/n/a/ac/ax
Standards:	IEEE802.3, IEEE802.3u, IEEE802.3ab
VPN Support:	PPTP server PPTP client L2TP client
WPA:	WPA-PSK,WPA2-PSK, WPA/WPA2-PSK • WPA3-SAE/WPA2-PSK • WPS Fast connection

Antenna

Antenna:	4 x 6dbi external antennas
Antenna Quantity:	4
Gain:	6 dBi

Management Features

Web-Based Management:

Yes

Ethernet LAN

Ethernet Interface Type:	Gigabit Ethernet
Ethernet LAN:	Yes
Ethernet LAN Data Rates:	10 • 100 • 1000 Mbit/s
Ethernet LAN Ports (RJ-45):	3

Wireless LAN

WIFI Band:	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi:	Wi-Fi 6 (802.11ax)
Wi-Fi Data Rate (Max):	2402 Mbit/s
Wi-Fi Standards:	802.11a • 802.11b • 802.11g • Wi-Fi 4 (802.11n) • Wi-Fi 5 (802.11ac) • Wi-Fi 6 (802.11ax)
Wireless Data Rates:	2.4GHz & 5GHz

Protocols

DHCP Client:	Yes
DHCP Server:	Yes
DMZ Support:	Yes
Port Forwarding:	Yes

Ports

WAN Connection:

Yes

Package Contents

Package Contents:

1 x Wireless Router • 1 x Ethernet Cable • 1 x Power Adapter • 1 x Installation Guide

Operational Conditions

Storage Temperature (T-T):

-40 - 70 °C

Physical Specification

Item Depth (mm):	162.85
Item Height (mm):	43.71
Item Width (mm):	272.44
LEDs:	1 x LED
Ports:	1 x 10/100/1000Mbps WAN ports • 3 x 10/100/1000Mbps LAN ports
Reset Button:	Yes
WPS Button:	Yes

Is the information for this product incomplete, wrong or inappropriate? Let us know about it.

Does this product have an incorrect or missing image? Send us a new image.

Is this product missing categories? Add more categories.

• Standard & Protocol: IEEE802.3, IEEE802.3u, IEEE802.3ab
• Interface: 1 x 10/100/1000Mbps WAN ports | 3 x 10/100/1000Mbps LAN ports
• Antenna: 4 x 6dbi external antennas
• Button: 1 x WPS/Reset button
• Power: Output:DC 12V1.5A
• LED indicator: 1 x LED
• Dimensions: (L x W x H) 272.44 x 162.85 x 43.71mm
• Wireless Standards: 802.11b/g/n/a/ac/ax
• Wireless Frequency: 5GHz: 2402Mbps | 2.4GHz: 574Mbps
• Wireless Data Rate: 2.4GHz & 5GHz
• Wireless Basic Functions: SSID broadcasting and hiding | MU-MIMO | Beamforming signal directional transmission technology | Support signal strength adjustment
• Wireless Security: WPA-PSK,WPA2-PSK, WPA/WPA2-PSK | WPA3-SAE/WPA2-PSK | WPS Fast connection
• Internet Connection Type: PPPOE, Dynamic IP, Static IP
• Network Protocol: IPv4 & IPv6
• Operating Mode: Wireless Router Mode | AP Mode
• DHCP: DHCP Server | DHCP Client List
• Security: Client Filter ( supports black list and white list ) | Parental Control ( supports black list and white list )
• Firewall: ICMP Flood Attack Defense | TCP Flood Attack Defense | UDP Flood Attack Defense | Ignore Ping Packet From WAN Port
• DDNS: Support DynDNS, No-ip
• Features: WPA3 | Dual-band | Wireless Signal Adjustment | Wi-Fi Timer Switch | Smart Power Saving | Panel LED Switch | Tenda App: Local and Remote Management
• Other Function: Bandwidth Control | Guest Network | IPTV | MAC Address Clone | Static Routing | System Log | System LogBackup Restore configurations | Firmware upgrade from local&online
• Temperature: Operating Temperature : 0℃~40℃ | Storage Temperature : -40℃ ~70℃
• Humidity: Operating Humidity : 10 %~90% RH non-condensing | Storage Humidity : 5 %~ 90%RH non-condensing
• Certification: CE, RoHS, FCC
• EIRP Power(Max.): 2.400-2.4835 GHz: 19.83dBm(EIRP) | 5.150-5.250 GHz: 22.98dBm(EIRP)
• Package Content: 1 x Wireless Router | 1 x Ethernet Cable | 1 x Power Adapter | 1 x Installation Guide
